T.06WFP1/490VA |
DRF-1/4"-90°-DN 06 |
06 |
G 1/4" |
|
inch |
A |
B |
C |
SW |
1/4" |
28,5 |
25,0 |
4,0 |
17 |
|
|
T.06WFP1/890VA |
DRF-1/8"-90°-DN 06 |
06 |
G 1/8" |
|
inch |
A |
B |
C |
SW |
1/4" |
31,0 |
17,0 |
4,0 |
14 |
|
|
T.08WFP1/490VA |
DRF-1/4"-90°-DN 08 |
08 |
G 1/4" |
|
inch |
A |
B |
C |
SW |
5/16" |
34,0 |
36,0 |
5,5 |
19 |
|
|
T.10WFP1/290VA |
DRF-1/2"-90°-DN 10 |
10 |
G 1/2" |
|
inch |
A |
B |
C |
SW |
3/8" |
41,5 |
36,0 |
7,0 |
27 |
|
|
T.10WFP3/890VA |
DRF-3/8"-90°-DN 10 |
10 |
G 3/8" |
|
inch |
A |
B |
C |
SW |
3/8" |
33,0 |
30,0 |
7,0 |
19 |
|
|
T.13WFP1/290VA |
DRF-1/2"-90°-DN 12 |
13 |
G 1/2" |
|
inch |
A |
B |
C |
SW |
1/2" |
44,0 |
36,5 |
9,5 |
27 |
|
|
T.13WFP3/490VA |
DRF-3/4"-90°-DN 12 |
13 |
G 3/4" |
|
inch |
A |
B |
C |
SW |
1/2" |
55,0 |
47,0 |
9,5 |
32 |
|
|
T.13WFP5/890VA |
DRF-5/8"-90°-DN 12 |
13 |
G 5/8" |
|
inch |
A |
B |
C |
SW |
1/2" |
44,5 |
47,5 |
9,5 |
27 |
|
|
T.16WFP3/490VA |
DRF-3/4"-90°-DN 16 |
16 |
G 3/4" |
|
inch |
A |
B |
C |
SW |
5/8" |
54,0 |
20,5 |
9,5 |
32 |
|
|
T.16WFP5/890VA |
DRF-5/8"-90°-DN 16 |
16 |
G 5/8" |
|
inch |
A |
B |
C |
SW |
5/8" |
54,5 |
50,0 |
12,0 |
27 |
|
|
T.19WFP190VA |
DRF-1"-90°-DN 19 |
19 |
G 1" |
|
inch |
A |
B |
C |
SW |
3/4" |
71,0 |
51,0 |
14,5 |
41 |
|
|
T.19WFP3/490VA |
DRF-3/4"-90°-DN 19 |
19 |
G 3/4" |
|
inch |
A |
B |
C |
SW |
3/4" |
61,0 |
50,0 |
14,5 |
32 |
|
|
T.25WFP1.1/490VA |
DRF-1 1/4"-90°-DN 25 |
25 |
G 1.1/4" |
|
inch |
A |
B |
C |
SW |
1" |
82,0 |
76,0 |
20,0 |
50 |
|
|
T.25WFP190VA |
DRF-1"-90°-DN 25 |
25 |
G 1" |
|
inch |
A |
B |
C |
SW |
1" |
75,0 |
64,5 |
20,0 |
41 |
|
|
T.32WFP1.1/290VA |
DRF-1 1/2"-90°-DN 31 |
32 |
G 1.1/2" |
|
inch |
A |
B |
C |
SW |
1.1/4" |
125,0 |
98,0 |
25,0 |
55 |
|
|
T.32WFP1.1/490VA |
DRF-1 1/4"-90°-DN 31 |
32 |
G 1.1/4" |
|
inch |
A |
B |
C |
SW |
1.1/4" |
87,0 |
74,5 |
25,0 |
50 |
|
|
T.38WFP1.1/290VA |
DRF-1 1/2"-90°-DN 38 |
38 |
G 1.1/2" |
|
inch |
A |
B |
C |
SW |
1.1/2" |
104,0 |
95,0 |
31,0 |
55 |
|
|
T.50WFP290VA |
DRF-2"-90°-DN 51 |
50 |
G 2" |
|
inch |
A |
B |
C |
SW |
2" |
142,0 |
119,0 |
40,0 |
70 |
|
