T.04UF1290VA |
DKL-M 12X1,5-90°-DN 05 |
04 |
M 12x1,5 |
8L |
|
Inch |
A |
B |
C |
SW |
3/16" |
29,0 |
33,0 |
3,0 |
14 |
|
|
T.06UF1290VA |
DKL-M 12X1,5-90°-DN 06 |
06 |
M 12x1,5 |
6L |
|
Inch |
A |
B |
C |
SW |
1/4" |
29,0 |
28,0 |
4,0 |
14 |
|
|
T.06UF1490VA |
DKL-M 14X1,5-90°-DN 06 |
06 |
M 14x1,5 |
8L |
|
Inch |
A |
B |
C |
SW |
1/4" |
28,5 |
27,0 |
4,0 |
17 |
|
|
T.08UF1690VA |
DKL-M 16X1,5-90°-DN 08 |
08 |
M 16x1,5 |
10L |
|
Inch |
A |
B |
C |
SW |
5/16" |
32,5 |
35,0 |
5,5 |
19 |
|
|
T.08UF1890VA |
DKL-M 18X1,5-90°-DN 08 |
08 |
M 18x1,5 |
12L |
|
Inch |
A |
B |
C |
SW |
5/16" |
34,0 |
36,0 |
5,5 |
22 |
|
|
T.10UF1690VA |
DKL-M 16X1,5-90°-DN 10 |
10 |
M 16x1,5 |
10L |
|
Inch |
A |
B |
C |
SW |
3/8" |
35,0 |
33,0 |
7,0 |
19 |
|
|
T.10UF1890VA |
DKL-M 18X1,5-90°-DN 10 |
10 |
M 18x1,5 |
12L |
|
Inch |
A |
B |
C |
SW |
3/8" |
34,5 |
35,0 |
7,0 |
22 |
|
|
T.13UF2290VA |
DKL-M 22X1,5-90°-DN 12 |
13 |
M 22x1,5 |
15L |
|
Inch |
A |
B |
C |
SW |
1/2" |
44,0 |
40,0 |
9,5 |
27 |
|
|
T.16UF2690VA |
DKL-M 26X1,5-90°-DN 16 |
16 |
M 26x1,5 |
18L |
|
Inch |
A |
B |
C |
SW |
5/8" |
55,0 |
49,0 |
12,5 |
32 |
|
|
T.19UF3090VA |
DKL-M 30X2-90°-DN 19 |
19 |
M 30x2 |
22L |
|
Inch |
A |
B |
C |
SW |
3/4" |
61,0 |
53,0 |
14,5 |
36 |
|
|
T.25UF3690VA |
DKL-M 36X2-90°-DN 25 |
25 |
M 36x2 |
28L |
|
Inch |
A |
B |
C |
SW |
1" |
80,0 |
67,5 |
20,0 |
41 |
|
|
T.32UF4590VA |
DKL-M 45X2-90°-DN 31 |
32 |
M 45x2 |
35L |
|
Inch |
A |
B |
C |
SW |
1.1/4" |
87,0 |
81,0 |
25,0 |
50 |
|
|
T.38UF5290VA |
DKL-M 52X2-90°-DN 38 |
38 |
M 52x2 |
42L |
|
Inch |
A |
B |
C |
SW |
1.1/2" |
104,0 |
100,0 |
31,5 |
60 |
|
